ElectraThane

Static Dissipative ESD Clear Coat for Epoxy Flooring

Stops Static Buildup!



Anti-Static Coating Applied to Epoxy

ElectraThane Anti-Static Clear Coat Over Epoxy



Itís easy to generate substantial static buildup while walking on many standard epoxy floors. The buildup may be mild to intense with rolling chairs and carts, and potentially deadly with fueling
aircraft.



ElectraThane controls static buildup by microscopically altering the texture of the smooth epoxy while adding a hygroscopic layer that increases electrical conductivity. This combination helps to harmlessly migrate the static to electrical ground. The results are stunning, often reducing the static voltage from a whopping 6.5kV to a mere 250 volts (well below the threshold of human perception).



When applied to ElectraGuard static conductive ESD Epoxy, ElectraThane will slightly raise the insulative properties while increasing the luster of ElectraGuard. This attribute is helpful when "adjusting" the minimum electrical resistivity upwards (perfect for munitions flooring that must comply with DOD 4145.26-M etc.).



Two to six thin coats of ElectraThane may also be used for elimination of nuisance static generation encountered with standard VCT, Ceramic Tiles and Garland, Sika, Stonehard or any standard thick set epoxy flooring.  ElectraThane does not contain carbon or metallic additives for its conductivity. Rather, it contains an active ingredient that effectively absorbs ambient humidity thus rendering the product static dissipative.



ElectraThane has a clean, fresh LOW odor and features excellent recoatability. ElectraThane is designed for mop on applications (2 to 6 coats) depending on the substrate. Please click here for application and maintenance.



PHYSICAL SPECIFICATIONS:



Nonvolatile Solids

20 +

Total Active / pH

26% / 8.4 - 9.0

AntiStatic Properties of 5 to 6 coats when applied to standard VCT Tiles, ElectraGuard Non Conductive (NC) and standard epoxy.

5,000 to < 500 @ <0.9 Seconds (50%rH).

<1.0E10 PTP per ANSI ESD S7.1

Static Dissipation / AntiStatic Properties when applied to ElectraGuard Conductive.

5,000 to < 500 @ < 1.2 Seconds (23%rH).

<1.0E10 PTP per ANSI ESD S7.1

Gloss 60

80+ @ 3 coats

Color

Translucent white

Weight Per Gallon

9.8 pounds

Slip Resistance (ASTM)

0.65 Minimum

Stability

2 year minimum at room temperature

Freeze/Thaw Stability

3 cycles minimum

Drying Time

60-90 minutes

Chemical Resistance

Good

Gallon Coverage (Feet 2 )

1500 - 2000

Removability (Gardner)

75 cycles maximum

This material is not a hazardous mixture, as defined in 29 CFR 1919, 1200 and M.G.L. c. 111F. Safety glasses and gloves should be worn during application and handling. If ingested drink milk, water, or fruit juice and induce vomiting with oil of ipecac. In the event of eye contact flush area with water for 15 minutes. Contact a Physician. For detailed information consult the SDS sheet.



SAFETY INFORMATION:

Health

1

Flammability

0

Reactivity

0

Personal Protection

B



EXTENDED INFORMATION:

APPLICATION and MAINTENANCE

DATA SHEET

DOWNLOAD SDS SHEET

MORE METHODS OF CONVERTING STANDARD EPOXY INTO ESD FLOORING



PRICING AND ORDERING INFORMATION:

1 gallon: PN E-Thane 1, $68.79 ea, weight 10 lbs

Case Lot (4 ea 1 gallon containers): $269.50*, 40 lbs

5 Gallon Pail: $318.95*, 50 lbs

*Note: Substantial Discount on 3+ Units.

Click to Buy Online
