Excellent static dissipative electrical performance that falls in the range recommended in the new ANSI ESD S20.20-2014. Dependable! Easily passes even the most sophisticated of esd audits. Wear resistant vinyl top surface, conductive inner scrim bonded to a soft yet durable foam base. ElectraSoft provides the ULTIMATE in mechanical shock protection AND ESD control. An excellent choice when working with sensitive electronics including hard drives, circuit boards, medical devices and sophisticated electronics.

antistatic THICK foam pad ElectraSoft ESD bench top static mats feature a closed cell static dissipative top layer permanently bonded to conductive inner scrim bonded to a soft, cushioning static dissipative closed cell bottom layer.

Perfect for protecting those mechanically sensitive ESD sensitive components. Fully dependable in audit situations when meeting ANSI ESD S 2020-2104 is a requirements. ElectraSoft isn't dependent on humidity for it's superb electrical decay rates. It's easy to keep clean and designed to provide years worth of dependable mechanical protection in concert with outstanding static control.

PHYSICAL PROPERTIES:

THICKNESS: .375 (3/8 of an inch)

COLORS: Sky Blue

AVAILABILITY: Pads, Full Rolls and Custom Cuts

ELECTRICAL PROPERTIES:

PTP PER ESD 4.1, 2006 >1.0E06 <1.0E09

RTG PER ESD 4.1, 2006: >1.0E06 <1.0E09

TYPICAL PTP @ 20%rH, 100VDC, 71 Deg F: 2.6.E08

TYPICAL RTG @ 20%rH, 100VDC, 71 Deg F: 8.1E07

Distribution Cut Sheet

3 Layer Vinyl Anti-Static Work Surface Mat
Product # 170-AS SKY BLUE

ROLL PRICING

30 inch x 60 feet

$1,212.49

Delivered Pricing! Continental USA and Canada!*

Click here to purchase, use the drop down to select your size

2 feet x 60 feet

$970.00

3 feet x 60 feet

$1,275.78

12 each 18" x 23"

$329.74

Pre Cut Pricing: Note - We have many more precut sizes available on our cart.

2' x 2'

$42.00

Delivered Pricing! Continental USA and Canada!* Many more lengths available! Need another length not shown? Simply call us for pricing and to place your order.

Click here to purchase, use the drop down to select your size

2' x 6'

$106.00

2' x 8'

$128.00

30 inch x 4'

$110.00

30 inch x 6'

$150.00

30 inch x 8'

$200.00

3' x 4'

$110.00

3' x 6'

$150.00

3' x 8'

$200.00

ASSOCIATED Items

To order 170-AS along with the following accessories using our new shopping cart please click here

ESD Constant Monitor - Our DT-020 Test the continuity of this matting material AND your wrist straps every second of the working day! Catch problems IMMEDIATELY! $73.33 (even less with quantity discounts).

Common Point Bench Mat Ground Cord - Our 113 AS snaps on a male 3/8 ground lug and has 2 inputs for wrist straps. This item includes the universal mat snap kit and installs with just a screwdriver. $8.97 each (even less with quantity discounts).

Universal mat snap kit - 3/8" - designed to fit nearly every thickness of esd bench top and floor mat. Available in Bag O' Tens Kits, only $11.00

Push and Cinch Male - 3/8" - The ultimate in a secure ground connection. Pierces all layers for ultimate conductivity. Bag O' Tens, $6.20 per bag

Push and Cinch Female - 3/8" - The ultimate in a secure ground connection. Pierces all layers for ultimate conductivity. Excellent for use with constant monitors, robust and fully compliant. Bag O' Tens, $6.20 per bag

ESD Mat Cleaner - Leaves Zero Insulative residues! Keeps table top and floor matting supple and helps rejuvenate the ESD mat's conductivity. Environmentally friendly, economical and Made in the USA! Available in quarts, cases, gallons and 5's! 1 quart WITH trigger sprayer, $8.22

Sales Associates: Old school precut calculator
