ElectraGuard Hi Gloss ESD Epoxy Flooring

ESD Two Part Epoxy Floor Paint with Sealers. Seamless Static Control Flooring for Electronic Manufacturing, Server Farms and Mission Critical ESD Control Areas!

Note: For DoD 4145.26-M and NFPA-484 Applications please click here.

The ElectraGuard ESD Flooring System easily meets the latest ANSI ESD S 20.20-2014 standards for static control (mandatory in 2017)! It's warranted for life time static conductivity and features a 10 year PLUS life expectancy. Unlike ESD Tiles and thick set epoxy, ElectraGuard features nanoparticle technology for amorphous and permanent static throughput. It's seamless, handles heavy loading and is resistant to high concrete vapor emissions (the number one cause of ESD Tile and thick set epoxy failures). Outstanding VALUE at a cost of approximately $1.30 psf!

THE ELECTRAGUARD HIGH GLOSS ESD FLOORING SYSTEM

ESD Epoxy Floor Paint in SMT Manufacturing Facility

United SCP Install of the Week, Fremont, California, U.S.A! ElectraGuard over standard VCT Tiles. A premier solution for this SMT area. Easily Compliant to the latest ANSI ESD Standards and a seamless solution to static control at less than 1/3 the cost of ESD Tiles.

ElectraGuard is a true two part epoxy paint that is fully compliant to the latest ANSI electrical standards for static control flooring. Unlike mere latex or other epoxy floor paints that may last a year or two the ElectraGuard High Gloss System provides outstanding longevity in concert with stellar static control performance!

The system consist of 2 to 3 coats of ElectraGuard followed by 2 thin coats of ElectraThane followed by one thin coat of ElectraGlaze Floor Finish. The ElectraGuard High Gloss System is designed for ultimate performance in demanding mission critical applications. It has a proven track record of clients that are experiencing a ten year or greater service life.  The system is well suited for application on a variety of substrates including concrete, existing well bonded VCT (standard tiles), and antistatic vinyl tiles and sheet goods and more. The ElectraGuard High Gloss ESD Floor Paint System meets or exceeds the latest most stringent standards of electrical conductivity including the new ANSI ESD S20.20-2014.

Install Gallery

ESD flooring applied around benches

Secret Location - Anonymous Defense Location and Primary Data Management

ElectraGuard Install Tecate Mexico

Elan ESD Flooring in Illinois

Smart Use of ESD Epoxy

Massachusetts

California

Mexico

Illinois

Arizona

meets S 20.20-2007 specifications for esd flooringWorld Wide Performance! A proven Performer!

outstanding for heavy loadsOutstanding resistance to vapor emissions, perfect for new construction.

perfect for class 0 static control, low tribo-chargingExtremely low tribo generation, perfect for Class Zero!

wear resistantOutstanding load carrying capabilities!

16 year track recordSixteen Year track record!

tough, chemical resistant and static conductiveWear performance that rivals esd tiles at 1/3 the cost!

easy to groundEasy to ground, Made in the USA!

fast applicationFast application, environmentally oriented!

easy to maintainEasy to maintain, lifetime conductivity!

24 / 7 tech support at no charge24/7 live tech support available at no charge with each order!  Inbound freight cost less than 1/4 compared to other flooring materials. Perfect for electronic assembly, manufacturing, munitions, air craft hangars, server rooms and more! For use over a multitude of substrates. Concrete, VCT, most paints and thick set epoxies.  Millions of square feet installed world wide!



New! Maintain the "look" of your ESD flooring throughout your entire facility! ElectraGuard NC (not for static control) at a cost of approximately $0.50 psf!



TYPICAL MAINTENANCE

Use brooms, dust mops, damp mops buckets and other cleaning tools dedicated for use on the ESD flooring only. Mark them as "for use in ESD area only." On a daily basis: Sweep the floor using a soft bristle broom to remove large abrasives such as wire clippings, nuts, bolts, etc. The use of a floor magnet to pick up ferrous metal shavings etc. helps avoid scratches. If the flooring is exceedingly dusty sweep it using an oil free sweeping compound that will leave no residue. If the flooring is slightly dusty simply dry dust mop. As needed: Damp mop using a diluted solution of ElectraClean and water. For more aggressive cleaning Auto Scrub the flooring to remove ground in dirt and contaminants. ElectraClean works well with all types of Auto Scrubbers. Use the softest pads available that will get the job done. To remove scuff marks: Spray buff using a high speed polisher equipped with a white or champagne colored pad and ElectraShine.

TYPICAL COVERAGE: 350 SF per Gallon Per Coat



Download Center



Colors

Specifications

Electrical Grounding

RoHS Compliance Statement

Installation Instructions

Concrete Repair

Warranty

5 Year Wear Study



SDS for Base     SDS for catalyst     Note: The catalyst is the same for all colors

Please note we are in the process of posting updates of the SDS sheets for ElectraGuard. In some cases an SDS is required for each color. Should you wish a new updated version immediately please contact us with the color you will be using and request the new versions.



SDS Sheet of Base by Color: Medium Gray



Architect's Specifier Sheet

Chemical Resistance

Cut Sheet for Distributors

Bond Strength Test Kit

Click HERE for a sample swatch

Click HERE for samples of the material to try on your substrate.

Click HERE for ElectraGuard application tools.

ESD Epoxy that is Made in the U.S.A.



Special of the Month!

Save over to $80 per Case or 5 gallon Container!

Only Online and ONLY from United SCP

Click HERE to Buy Online!



NOTES and Additional Information: ElectraGuard Anti Static Flooring has been successfully used by Major Companies for over 16 years and meets the latest standards of ANSI/ESD S20.20 for esd conductive flooring. ElectraGuard Flooring is a thin set epoxy applied using paint rollers. As such, minor deviations in thickness, texture, color and shading may be present in the coating. Deviations in concrete profile may shadow through any thin set epoxy or floor paint. United recommends the use of Titanium esd chair mats in front of the workstation to protect any esd flooring from chair caster damage. Dye Lots may vary. For best results place your order for the entire amount needed for the current project plus possible future expansions. Prior to opening the pails check dye lots and materials against your purchase order. IMPORTANT! United makes every effort to ship the correct product, contact us immediately should you receive the wrong material. United SCP is not responsible for installation of the incorrect material, color or dye lot due to errors in pulling your order. The shelf life of the product is 2 years as long as it is stored in a cool dry climate and in unopened containers. ElectraGuard as applied does not have a shine. It is a low glare matte finish. For a high shine finish, top coat with the ElectraThane and ElectraGlaze.
