ESD CLEAN ROOM BENCH MAT FOR STATIC CONTROL

Ultimat is a new technology static dissipative industrial grade elastomeric designed for use on tables and other workbench surfaces. Its electrical properties are volume dissipative unlike many of the surface dissipative properties of the competition. This material was developed to conform to the new Class Zero and RoHS requirements. Ultimat CR White is chemically cross-linked throughout the entire thickness of the material providing permanent volume esd conductivity in combination with polymers that will not exudate nor outgas and contaminate in clean rooms and other sensitive environments. Ultimat CR White is as durable as rigid laminates and as comfortable and appealing as the softer rubber tablemats. Not recommended for use with continuous esd mat monitors.

This material meets both the US EOS 20/20 and European IEC 613450-5-1 specifications and therefore has outstanding charge dissipation, rapid charge decay, no charge suppression and outstanding low tribogeneration properties. The material will withstand solvents, soldering iron deformation, not curl, and have excellent abrasion resistance. The embossed surface will reduce light glare, increase part slip resistance, and facilitate cleaning. since the material is free from halogens, lead, arsenic, barium, heavy metals, phthalate plasticizers, vinyl monomer, asbestos, formaldehyde, antimony, chromium, cadmium, and other dangerous volatiles it may be used in environments where out gassing and contamination is of concern. It is RoHS compliant. A full set of test results for out gassing and compatibility is available from Galbraith Labs, K+S Labs, and Balasz Test Labs.

Properties:

• Embossed Finish

• Reversible - Both sides are white

• .070-.080 inch (1.8mm) thickness

• .05 sec decay time

• 10⁷ – 10⁸ ohm, ohm-cm, RTG, RTT, Vol R

• Available in white

• Widths: 24, 30, and 48 inches

• Lengths: 40 feet

• Durable surface

• Low abrasion

• No vinyl monomers or DOP

• UV Additives

Benefits:

• No glare, easy cleaning, no part sticking

• Durability, non curling, lays flat

• Rapid, safe static drain

• Meets all electrical specifications-all humidity's

• Aesthetically appealing

• Fits all benches. Other widths available

• Easy to cut and ship to weight limitations

• Will withstand temperature, solder, flux, and harsh chemicals

• Ideal for clean rooms and other controlled areas

• Durability

• Environmental and personnel safety and conformance

• Color Stability

Precut Mats	Roll Material
CM-2436 - 24in x 36in Mat MSRP: $68.00 US CM-2448 - 24in x 48in Mat MSRP: $89.00 US CM-2460 - 24in x 60in Mat MSRP: $110.00 US	CR-2440 - 40ft x 24in Roll MSRP: $638.00 US CR-3040 - 40ft x 30in Roll MSRP: $797.00 US
Note: The above products are not included in our free shipping program.
